Contents English
1. Symbols used 25
1.1 In the documentation 25
1.1.1 Warning notices - Structure and meaning
25
1.1.2 Symbols in this documentation 25
1.2 On the product 25
2. WBE 4140 26
�. How to use the machine and surfing menu 27
3.1 Display 27
3.2 Control keys 27
3.3 Menu navigation 27
3.3.1 Auto-diagnosis 27
3.3.2 Calibration 27
3.3.3 Settings 28
3.3.4 User-defined settings 28
4. Faults 29
5. How to up-to-date the software �1
6. Configuration of the board �1
7. Standard calibration �2
7.1 Recalling of the calibration menu 32
7.2 Calibration with wheel and sample weight 32
7.3 Flange calibration 32
7.4 Calibration of electronic vernier caliper/gauge
arm 32
7.4.1 Reference measurement 34
7.5 Factory calibration 34
7.5.1 Recalling of the calibration menu 34
7.5.2 Calibration with sample weight 34
7.5.3 Flange calibration 35
7.5.4 Calibration of electronic calliper gauge/
measurement arm 35
7.5.5 Factory settings 35
8.2 Pick-up 36
8. Diagnostics �6
8.1 Recalling of the diagnostics menu 36
8.2.1 Check of the phase difference 37
8.2.2 Check of the external pick-up sensor
(IN0) 37
8.2.3 Check of the internal pick-up sensor
(IN1) 38
8.3 Encoder 38
8.4 Engine and power board 38
8.4.1 Check belt tensioning 38
8.5 Potentiometers 38
8.5.1 Diagnosis distance potentiometer(IN2) 38
8.5.2 Diagnosis width potentiometer(IN3) 38
8.5.3 Diagnosis diameter potentiometer (IN4)
39
8.6 Ingressi ed uscite digitali 39
8.6.1 Protection micro switch 39
9. Replacement interventions �9
9.1 Pick-up replacement 39
9.2 Replacement Easy Aludata calliper 40
9.3 Width potentiometer positioning procedure 40
9.4 Diameter potentiometer positioning procedure
41
9.5 Engine belt replacement 41
9.6 Power board replacement 42
9.7 Video board replacement procedure 42
10. Suggested spare parts 4�
11. Electric system 44
