1. Symbols used
1.1 In the documentation
1.1.1 Warning notices - Structure and meaning
Warning notices indicate hazards and their
consequences for the user or surrounding persons.
Warning notices also describe the measures for
preventing these hazards.
The signal word has a crucial importance. It indicates
the probability of occurrence and the severity of the
hazard in case of non-compliance:
Signal
word
Probability of
occurrence
Severity of danger
if instructions not
observed
DANGER Immediate impending
danger
Death
or severe
injury
Possible impending
danger
Death
or severe
injury
CAUTION Possible dangerous
situation
Minor
injury
Below you will see an example of the “Live parts”
warning notice by way of example, with the signal word
DANGER:
DANGER – Exposure of live parts on
opening the WBE 4140!
Risk of (fatal) injury or heart failure
from electric shocks on contact with live
components (e.g. master switch, printed
circuit boards).
¶ Work on electrical installations or
equipment is only to be performed by
qualified electricians or trained personnel
under the guidance and supervision of an
electrician.
¶
Disconnect KTS 340 from the mains before
opening.
1.1.2 Symbols in this documentation
Sym-
bol
Designation Explanation
!
Attention Warns about possible property damage.
i
Information Practical hints and other
useful information.
1.
2.
Multi-step
operation
Instruction consisting of several steps
e
One-step
operation
Instruction consisting of one step.

Intermediate
result
An instruction produces a visible
intermediate result.
"
Final result There is a visible final result on
completion of the instruction.
DANGER – Exposure of live parts on
opening the WBE 4140!
Risk of (fatal) injury or heart failure
from electric shocks on contact with live
components (e.g. master switch, printed
circuit boards).
¶ Work on electrical installations or
equipment is only to be performed by
qualified electricians or trained personnel
under the guidance and supervision of an
electrician.
¶ Disconnect the WBE 4140 from the mains
before opening.
Disposal
Dispose of used electrical and electronic
devices, including cables, accessories and
batteries, separately from household waste.
1.2 On the product
! Observe all warning notices on products and ensure
they remain legible!
Direction of wheel rotation
Wheel must turn in direction indicated.
