65
Figure 8. 3
•2•1 Series II Console Test Setup Diagram
Video
Monitor
RF Signal 
Generator
IBM 
compatible 
PC
ETAP cable
dB meter
SPDIF converter
Optical converter
Audio Signal 
Generator
Composite, S-Video
and Component
inputs
Audio,
SPDIF
or Optical
input
Audio output
RF input
Console DC power
and test cable
Lifestyle DC power
supply, part number
256764-001
3 2 1 II Console
