66
Figure 9. 3
•2•1 Series II Bass Module Test Setup Diagram
IBM 
compatible 
PC
SPDIF converter
Audio Signal 
Generator
Analog Audio or
SPDIF input
3 2 1 II Bass Module
Bass Module
Test Cable
Null Modem Cable from PC Com Port
Smart Speaker commands from PC
