Bose ControlSpace ESP-00 II - Main Part List, Controlspace ESP-00 II Chassis (See Figure 4)

13
MAIN PART LIST
ControlSpace
®
ESP-00 II Chassis (see Figure 4)
Item
Number
Description Vendor Part Number Bose
®
Part
Number
Qty. Note
1 FRONT PANEL, ALUMINUM BSET8571-01162 369714-0010 1
2 LIGHT PIPE BSET70G1-01162 369716-0010 9
3 LIGHT GUIDE, SLEEVE BSET7211-01162 369717-0110 11
4 FRONT PANEL, STEEL BSET8571-01161 369715-0110 1
5 RACK EAR, METAL BRKT, 2U BSET8222-01163 361005-0110 2
6 SCREW, RACK EAR, M4X12PH BSET6512E00111 370494-0110 4
7 SCREW, FRONT PANEL, M3X4-
MSF
BSET6532D00111 370495-0110 4
8 SCREW, M3.5, BTITE, SELF
TAPPING
BSET6552C00211 - 6 2
9 CHASSIS BSET8341-01162 - 1 2
10 PCB FIXED STICK, BELOW BSET71A1-01021 278504-001 1
11 DSP HI-PERF EXPANSION PCB - 720112-001S 1
12 DSP PCB ASSY, STD PERF. - 720111-001S 1
13 CABLE CLAMP, NYL, 6.2MM BSET7.31-01021 - 1 2
14 CABLE CLAMP, NYL, 3.0MM BSET7031-02021 - 1 2
15 RUBBER RIVET, BLK BSET7141-01022 331160-0010 4
16 FAN, DC, LOW NOISE BSET24CS101022 331159-0100 1 3
17 SCREW, MSB, M3X4 BSET6512E00311 - 56 2
18 POWER SUPPLY PCB ASSY BSET80A1-01021 331162-001S 1 3
19 GPIO PCB ASSY, 8 IN, 8 OUT BSE11A1 299005 1
20 AC POWER SWITCH, ROCKER,
SPST, 125V/15A
BSET2241100112 - 1 2,3
21 SOCKET, AC INLET, IEC,
250V/10A
BSET4013-0011C - 1 2,3
22 REAR PANEL, GIO BSET8221-03021 278516-0110 1
23 REAR PANEL, DSP BSET8221-04021 278515-0110 1
24 METAL COVER BSET8331-01162 278505-0110 1
25 STAY BSET8331-02021 278508-001 1
26 BLANK PANEL BSET8221-06021 278518-0110 9
27 PCB FIXED STICK, ABOVE BSET71A1-02021 278503-001 2
28 MOTHERBOARD PCB ASSY,
REV. C
- 720110-001S 1
29 WASHER BSET6335-00111 - 12 2
30 SCREW, MSF, M3X4 BSET6532E00111 - 4 2
31 STANDOFF, M3X18.5MM BSET67G-C00111 - 4 2
32 HEX NUT W/NYLON INSERT, SI,
M3MM
BSET8925F00111 - 2 2
33 SCREW, SI, MSB, M3X6MM BSET6512E00211 - 6 2
34 SCREW, SI, MSB, M3X8MM BSET6512E00411 - 2 2
35 WIRE ASSY W/2HSG, 20 AWG
(ASTEC POWER SUPPLY
WIRING HARNESS)
BSET3721-04022 318935-001S 1 3
36 WIRE HSG/TER, 20 AWG,
L=160MM
BSET37D1-02021 - 1 2
37 WIRE, 2 TER, 18 AWG, L=160MM,
Y/G
BSET37C1-02022 - 1 2
38 WIRE ASSY W/2 TER, 18 AWG BSET37C1-01022 - 1 2
39 WIRE ASSY W/FEMALE, 20 AWG,
L=80MM
BSET37A1-01021 - 1 2
40 WIRE W/2HSG, 26 AWG, GIO BSET3721-05022 - 1 2
