Bose ControlSpace ESP-00 II - Zone Controller

65
ELECTRICAL PART LIST
CC-16 Zone Controller
Resistors
Capacitors
Diodes
Reference
Designator
Description
V
endor Name
V
endor Part
Number
Note
R1 715 OHM, 0603, 1/10W, 1% Yageo Corporation RC0603FR-07715R
R2 240 OHM, 0603, 1/10W, 1% Ya
g
eo Cor
p
ora
t
ion RC0603FR-07240R
R3 100K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-07100K
R4 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R5 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R8 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R6 120 OHM, 1206, 1/4W, 5% Yageo Corporation RC1206JR-07120R
R7 1.2K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-071K2
R9 1.2K, 0603, 1/10W, 5% Ya
g
eo Cor
p
oration RC0603JR-071K2
R11 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R12 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R13 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R14 10K, 0603, 1/10W, 5% Ya
g
eo Cor
p
oration RC0603JR-0710K
R15 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R16 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R17 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R18 10K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0710K
R10 47K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-0747K
R22 4.7K, 0603, 1/10W, 5% Yageo Corporation RC0603JR-074K7
Reference
Designator
Description
V
endor Name
V
endor Part
Number
Note
C1 47uF, 50V, SMD, ECAP,
+105/-55C, 20%, D6.3x7.7
Nichicon Corp
UUD1H470MCR1GS
C2 100uF, 16V, SMD, ECAP,
+105/-55C, 20%, D6.3X5.4
Nichicon Corp
UWT1C101MCR1GB
C3 20pF, 0603, 50V, NPO, 5% Teamyoung Corp 0603N200J500BB
C4 20
p
F, 0603, 50V, NPO, 5% Team
y
oun
g
Cor
p
0603N200J500BB
C5 220pF, 0603, 50V, NPO, 5% Teamyoung Corp 0603N221J500BB
C6 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB
C7 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB
C8 0.1uF, 0603, X7R, 16V, 10% Team
y
oun
g
Cor
p
0603B104K160BB
C9 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB
C10 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB
C11 0.1uF, 0603, X7R, 16V, 10% Team
y
oun
g
Cor
p
0603B104K160BB
C12 0.1uF, 0603, X7R, 16V, 10% Teamyoung Corp 0603B104K160BB
Reference
Designator
Description
V
endor Name
V
endor Part
Number
Note
D1 SCHOTTKY BAR
R
, SOD-80C Philips Semi BAS85
D2 SCHOTTKY BARR, SOD-80C Phili
p
s Semi BAS85
D3 SCHOTTKY BARR, SOD-80C Philips Semi BAS85
D4 SCHOTTKY BARR, SOD-80C Philips Semi BAS85
- RECT, 400V/1
A
, SOD-106 Rohm Semi 1SR154-400
