ELECTRICAL PART LIST
CC-64 Control Center
Resistors
Capacitors
Reference
Designator
Description
V
endor
Name
V
endor Part
Number
Note
RA100 NETWORK, 10K, 10 PIN/8R, 5% Yageo YC158TJR-0710K
RA400 NETWORK, 10K, 10 PIN/8R, 5% Ya
g
eo
YC158TJR-0710K
RA401 NETWORK, 10K, 10 PIN/8R, 5% Yageo
YC158TJR-0710K
RA500 NETWORK, 10K, 10 PIN/8R, 5% Yageo YC158TJR-0710K
R100 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R101 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R102 47 OHM, 0603, 1/10W, 5% Yageo
RC0603JR-0747R
R103 47 OHM, 0603, 1/10W, 5% Yageo RC0603JR-0747R
R104 10K, 0603, 1/10W, 1% Ya
g
eo
RC0603FR-0710K
R105 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R106 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R107 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R108 10K, 0603, 1/10W, 1% Ya
g
eo
RC0603FR-0710K
R109 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R200 330 OHM, 0603, 1/10W, 1% Yageo
RC0603FR-07330R
R201 47 OHM, 0603, 1/10W, 5% Yageo RC0603JR-0747R
R202 47 OHM, 0603, 1/10W, 5% Yageo
RC0603JR-0747R
R203 330 OHM, 0603, 1/10W, 1% Yageo
RC0603FR-07330R
R204 330 OHM, 0603, 1/10W, 1% Yageo
RC0603FR-07330R
R205 100 OHM, 0603, 1/10W, 1% Ya
g
eo
RC0603FR-07100R
R206 100 OHM, 0603, 1/10W, 1% Yageo
RC0603FR-07100R
R208 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R209 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R210 330 OHM, 0603, 1/10W, 1% Ya
g
eo
RC0603FR-07330R
R212 47 OHM, 0603, 1/10W, 5% Yageo
RC0603JR-0747R
R216 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R300 56K, 0603, 1/10W, 1% Yageo RC0603FR-0756K
R400 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R401 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R402 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R403 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R404 0 OHM, 0603, 1/10W, 5% Yageo
RC0603JR-07R00
R500 0 OHM, 0603, 1/10W, 5% Yageo
RC0603JR-07R00
R501 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R502 0 OHM, 0603, 1/10W, 5% Ya
g
eo
RC0603JR-07R00
R505 10K, 0603, 1/10W, 1% Yageo
RC0603FR-0710K
R506 1K, 0603, 1/10W, 1% Yageo
RC0603FR-071K
R509 680 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07680R
Reference
Designator
Description
V
endor
Name
V
endor Part
Number
C100 12pF, 0603, NPO, 50V, 125C, 5% Samsung CL10C120JBNC
C101 12
p
F, 0603, NPO, 50V, 125C, 5% Samsun
g
CL10C120JBNC
C102 10uF, SMD E CAP, 16V, 105C, 20% Nichicon
UZT1C100MCR1GB
C103 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C104 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
