ELECTRICAL PART LIST
Capacitors (continued)
CC-64 Control Center
Reference
Designator
Description
V
endor
Name
V
endor Part
Number
C105 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C106 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsun
g
CL10F104ZBNC
C107 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C108 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C109 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C110 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C200 1000pF, CER, Y5P, 2KV, 125C, 10% Panasonic
ECKD3D102KBP
C201 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung CL10B103KBNC
C202 0.01uF, 0603, X7R, 50V, 125C, 10% Samsun
g
CL10B103KBNC
C203 12pF, 0603, NPO, 50V, 125C, 5% Samsung
CL10C120JBNC
C204 12pF, 0603, NPO, 50V, 125C, 5% Samsung
CL10C120JBNC
C205 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C206 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsun
g
CL10F104ZBNC
C207 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C208 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C209 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C210 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C211 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C213 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C214 1000
p
F, CER, Y5P, 2KV, 125C, 10% Panasonic
ECKD3D102KBP
C300 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C301 22pF, 0603, NPO, 50V, 125C, 5% Samsung
CL10C220JBNC
C302 10uF, SMD E CAP, 16V, 105C, 20% Nichicon UZT1C100MCR1GB
C400 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsun
g
CL10F104ZBNC
C401 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C402 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C403 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C404 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C405 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C406 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung CL10B103KBNC
C407 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung CL10B103KBNC
C408 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C409 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C410 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung CL10B103KBNC
C411 0.01uF, 0603, X7R, 50V, 125C, 10% Samsun
g
CL10B103KBNC
C412 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C413 0.01uF, 0603, X7R, 50V, 125C, 10% Samsung
CL10B103KBNC
C500 220uF, SMD E CAP, 10V, 105C, 20% Nichicon
UWT1A221MCL1GS
C501 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsun
g
CL10F104ZBNC
C502 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C503 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C504 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung CL10F104ZBNC
C505 220uF, SMD E CAP, 10V, 105C, 20% Nichicon
UWT1A221MCL1GS
C507 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C508 0.1uF, 0603, Y5V, 50V, 85C, 20% Samsung
CL10F104ZBNC
C509 10uF, E CAP, 16V, 105C, 20% Nichicon
UZT1C100MCR1GB
