Bose ControlSpace ESP-00 II - Main Part List, Controlspace CC-16 Controller

15
MAIN PART LIST
ControlSpace
®
CC-16 Controller
Figure 5. ControlSpace CC-16 Controller Exploded View
Item
Number
Description Qty.
Part Number
Note
1 Front plate, PC, GE, LEXAN, 241R, White 1 275432
2 Overlay, PC sheet, w/adhesive, 0.18mm 1 277488
3 Insert, plate, PC, GE, LEXAN, 241R, White 1 275434 2
4 LCD PCB Assembly 1 275817-002
5 Mounting Frame, PC, GE, LEXAN, 241R, White 1 275433 2
6 Main PCB Assembly 1 275817-001
