Bose ControlSpace ESP-00 II - Output PCB Assembly; LED PCB Assembly; Diodes

59
ELECTRICAL PART LIST
Output PCB Assembly
Inductors
Miscellaneous
Diodes
LED PCB Assembly
Reference
Designator
Description
V
endor
Name
V
endor Part Number Note
L900 NFM39R12C223 MURATA NFM39R12C223
L901 NFM39R12C223 MURATA NFM39R12C223
L902 NFM39R12C223 MURATA NFM39R12C223
L903 NFM39R12C223 MURATA NFM39R12C223
L904 NFM39R12C223 MURATA NFM39R12C223
L905 NFM39R12C223 MURATA NFM39R12C223
L906 NFM39R12C223 MURATA NFM39R12C223
L907 NFM39R12C223 MURATA NFM39R12C223
L908 NFM39R12C223 MURATA NFM39R12C223
L909 NFM39R12C223 MURATA NFM39R12C223
L910 NFM39R12C223 MURATA NFM39R12C223
L911 NFM39R12C223 MURATA NFM39R12C223
Reference
Designator
Description
V
endor
Name
V
endor Part Number Note
CN900 STLZ950/3G-5.08 FENIX-
CONTACT
STLZ950/3G-5.08
CN901 STLZ950/3G-5.08 FENIX-
CONTACT
STLZ950/3G-5.08
CN902 STLZ950/3G-5.08 FENIX-
CONTACT
STLZ950/3G-5.08
CN903 STLZ950/3G-5.08 FENIX-
CONTACT
STLZ950/3G-5.08
CN904 0T1-400334 CT 0T1-400334
Reference
Designator
Description
V
endor
V
endor Part Number Note
D920 LED, RED/GREEN SHARP GL3ED8(R/G)
D921 LED, RED/GREEN SHARP GL3ED8
(
R/G
)
D922 LED, RED/GREEN SHARP GL3ED8(R/G)
D923 LED, RED/GREEN SHARP GL3ED8(R/G)
D924 LED, RED/GREEN SHARP GL3ED8(R/G)
D925 LED, RED/GREEN SHARP GL3ED8(R/G)
D926 LED, RED/GREEN SHARP GL3ED8(R/G)
D927 LED, RED/GREEN SHARP GL3ED8(R/G)
