ELECTRICAL PART LIST
Resistors
ESP-00 II Motherboard PCB Assembly (Rev. B)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R100 10
k
RK73H1JTD10KF KOA
R101 1
k
RK73H1JTD1KF KOA
R102 0 Ohm RK73Z1JTD 0RJ KOA
R103 0 Ohm RK73Z1JTD 0RJ KOA
R104 0 Ohm RK73Z1JTD 0RJ KOA
R105 0 Ohm RK73Z1JTD 0RJ KOA
R106 10k RK73H1JTD10KF KOA
R107 10k RK73H1JTD10KF KOA
R108 10
k
RK73H1JTD10KF KOA
R109 10k RK73H1JTD10KF KOA
R110 10k RK73H1JTD10KF KOA
R111 0 Ohm RK73Z1JTD 0RJ KOA
R112 0 Ohm RK73Z1JTD 0RJ KOA
R113 0 Ohm RK73Z1JTD 0RJ KOA
R114 0 Ohm RK73Z1JTD 0RJ KOA
R115 68 Ohm RK73H1JTD68RF KOA
R116 68 Ohm RK73H1JTD68RF KOA
R117 68 Ohm RK73H1JTD68RF KOA
R118 0 Ohm RK73Z1JTD 0RJ KOA
R119 0 Ohm RK73Z1JTD 0RJ KOA
R120 0 Ohm RK73Z1JTD 0RJ KOA
R200 220k RK73H1JTD220kF KOA
R201 8.2k RK73H1JTD8.2KF KOA
R202 12
k
RK73H1JTD12KF KOA
R203 OPEN NOT USED NOT USED
R204 10k RK73H1JTD10KF KOA
R205 2.2k RK73H1JTD2.2KF KOA
R211 1k RK73H1JTD1KF KOA
R213 1k RK73H1JTD1KF KOA
R214 10k RK73H1JTD10KF KOA
R215 10
k
RK73H1JTD10KF KOA
R216 10k RK73H1JTD10KF KOA
R220 2.2k RK73H1JTD2.2KF KOA
R221 2.2k RK73H1JTD2.2KF KOA
R222 33 Ohm RK73H1JTD33RF KOA
R223 33 Ohm RK73H1JTD33RF KOA
R236 220k RK73H1JTD220kF KOA
R237 OPEN NOT USED NOT USED
R238 10
k
RK73H1JTD10KF KOA
R239 2.2k RK73H1JTD2.2KF KOA
R240 8.2k RK73H1JTD8.2KF KOA
R241 12
k
RK73H1JTD12KF KOA
R300 68 Ohm RK73H1JTD68RF KOA
R301 68 Ohm RK73H1JTD68RF KOA
R302 68 Ohm RK73H1JTD68RF KOA
R303 33 Ohm RK73H1JTD33RF KOA
