Bose ControlSpace ESP-00 II - Digital Signal Processor (DSP) PCB Assembly

45
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Resistors
Reference
Designator
Description
V
endor
V
endor Part Number Note
R100 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R101 1K, 0603, 1/10W, 1% Yageo RC0603FR-071K
R102 1K, 0603, 1/10W, 1% Ya
g
eo RC0603FR-071K
R103 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R104 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R105 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R106 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R107 10K, 0603, 1/10W, 1% Ya
g
eo RC0603FR-0710K
R108 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R109 110 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07110R
R110 110 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07110R
R111 110 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07110R
R200 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R201 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R202 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R
R203 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R204 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R205 33 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603FR-0733R
R206 1K, 0603, 1/10W, 1% Yageo RC0603FR-071K
R208 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R210 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R211 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R212 33 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603FR-0733R
R213 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R214 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R215 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R216 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R219 33 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603FR-0733R
R220 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R300 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R301 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R302 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R303 0 OHM, 0603, 1/10W, 5% Ya
g
eo RC0603JR-07R00
R306 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R307 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R309 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R310 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R311 4.7K, 0603, 1/10W, 1% Ya
g
eo RC0603FR-074K7
R312 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R313 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R316 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R318 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R321 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R401 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R402 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R403 8.2 OHM, 0603, 1/10W, 1% Yageo RC0603FR-078R2
R404 8.2 OHM, 0603, 1/10W, 1% Yageo RC0603FR-078R2
R407 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R408 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
