Bose ControlSpace ESP-00 II - Page 46

46
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Resistors (continued)
Resistor Arrays
Reference
Designator
Description
V
endor
V
endor Part Number Note
R409 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R410 220K, 0603, 1/10W, 1% Yageo RC0603FR-07220K
R450 4.7K, 0603, 1/10W, 1% Ya
g
eo RC0603FR-074K7
R451 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R452 560K, 0603, 1/10W, 1% Yageo RC0603FR-07560K
R457 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R458 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R459 180 OHM, 0603, 1/10W, 5% Ya
g
eo RC0603J
R
-07180R
R460 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R461 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R462 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R463 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R464 180 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07180R
R465 4.7K, 0603, 1/10W, 1% Yageo RC0603FR-074K7
R466 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R467 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R468 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R469 0 OHM, 0603, 1/10W, 5% Ya
g
eo RC0603J
R
-07R0
0
R470 68K, 0603, 1/10W, 1% Yageo RC0603FR-0768K
R475 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R
R476 820 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07820R
R477 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R478 390 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603FR-07390R
R479 820 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07820R
R480 12K, 0603, 1/10W, 1% Yageo RC0603FR-0712K
R481 1.2K, 0603, 1/10W, 1% Yageo RC0603FR-071K2
R482 120 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07120R
R483 1.2K, 0603, 1/10W, 1% Ya
g
eo RC0603FR-071K2
R535 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R536 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R537 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R538 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R539 33 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603FR-0733R
R540 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R541 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
R542 33 OHM, 0603, 1/10W, 1% Yageo RC0603FR-0733R
Reference
Designator
Description
V
endor
V
endor Part Number Note
RA100 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA101 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA102 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA103 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA104 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA105 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA106 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA107 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA108 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
