ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Resistor Arrays (continued)
Reference
Designator
Description
V
endor
V
endor Part Number Note
RA109 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA110 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA111 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA200 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA201 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA202 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA203 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA204 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA205 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA206 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA207 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA208 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA209 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA210 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA211 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA212 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA213 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
R
A
214 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA215 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA216 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA217 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA218 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA219 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA220 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA221 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA222 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA223 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA224 10K, ARRAY, 10 PIN, 8R, 5% Ya
g
eo YC158TJR-0710K
RA300 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA301 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA302 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA303 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA304 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA305 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA306 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA307 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA308 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA309 33 OHM, ARRAY, 8 PIN, 5% Ya
g
eo YC164-JR-0733R
RA310 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA311 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA312 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA313 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA314 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA315 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA316 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA317 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA318 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA319 33 OHM, ARRAY, 8 PIN, 5% Yageo YC164-JR-0733R
RA400 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
