48
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Resistor Arrays (continued)
Capacitors
Reference
Designator
Description
V
endor
V
endor Part Number Note
RA401 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA450 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA530 10K, ARRAY, 10 PIN, 8R, 5% Ya
g
eo YC158TJR-0710K
RA531 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA532 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
RA533 10K, ARRAY, 10 PIN, 8R, 5% Yageo YC158TJR-0710K
Reference
Designator
Description
V
endor
V
endor Part Number Note
C100 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C101 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C102 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C103 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C104 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C105 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C106 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C107 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C108 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C109 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C110 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C111 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C112 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C113 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C114 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C115 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C116 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C117 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C118 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C119 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C120 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C121 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C122 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C123 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C124 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C125 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C126 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C127 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C128 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C129 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C130 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C131 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C132 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C133 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C134 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C135 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C136 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C137 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C138 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
