Bose ControlSpace ESP-00 II - 4 X4 Series II PCB Assembly (Optional on ESP-00 II)

43
ELECTRICAL PART LIST
Integrated Circuits
Transistors (continued)
4x4 Series II PCB Assembly (optional on ESP-00 II)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
Q402 DTC114EKA DTC114EK
A
RHOM
Q403 2SC3326 2SC3326 TOSHIBA
Q404 2SC3326 2SC3326 TOSHIBA
Q405 2SC3326 2SC3326 TOSHIBA
Q406 2SC3326 2SC3326 TOSHIBA
Q407 DTC114EKA DTC114EKA RHOM
Q408 DTA114EKA DTA114EKA RHOM
Q409 DTC114EKA DTC114EKA RHOM
Q700 DTC114EKA DTC114EK
A
RHOM
Q701 DTC114EKA DTC114EKA RHOM
Q702 DTC114EKA DTC114EKA RHOM
Q703 DTC114EKA DTC114EKA RHOM
Q704 DTC114EKA DTC114EK
A
RHOM
Q705 DTC114EKA DTC114EKA RHOM
Q706 DTC114EKA DTC114EKA RHOM
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
M100 TC9164CFG TC9164CFG TOSHIBA
M101 NJM4580E NJM4580ETE2
(
JRC
)
JRC
M102 NJM4580E NJM4580ETE2(JRC) JRC
M103 NJM4580E NJM4580ETE2(JRC) JRC
M104 NJM4580E NJM4580ETE2(JRC) JRC
M200 TC9164CFG TC9164CFG TOSHIBA
M201 NJM4580E NJM4580ETE2(JRC) JRC
M202 NJM4580E NJM4580ETE2(JRC) JRC
M203 NJM4580E NJM4580ETE2
(
JRC
)
JRC
M204 NJM4580E NJM4580ETE2(JRC) JRC
M300 NJM4580E NJM4580ETE2(JRC) JRC
M301 NJM4580E NJM4580ETE2(JRC) JRC
M302 NJM4580E NJM4580ETE2
(
JRC
)
JRC
M303 NJM4580E NJM4580ETE2(JRC) JRC
M400 NJM4580E NJM4580ETE2(JRC) JRC
M401 NJM4580E NJM4580ETE2(JRC) JRC
M402 NJM4580E NJM4580ETE2(JRC) JRC
M403 NJM4580E NJM4580ETE2(JRC) JRC
M500 CS5361-KZ CS5361-KZ CIRRUS
M501 CS5361-KZ CS5361-KZ CIRRUS
M550 CS4392-KZ CS4392-KZ CIRRUS
M551 CS4392-KZ CS4392-KZ CIRRUS
M700 74VHC541 TC74VHC541FT TOSHIBA
M701 74VHC541 TC74VHC541FT TOSHIBA
M702 74AC273 TC74AC273FT TOSHIBA
M703 S-80947CNMC-G9H S-80947CNMC-G9H SEIKO
M704 TA48033F uPC2933T TOSHIBA
M705 TA7805F uPC2905AT TOSHIBA
M707 74AC273 TC74AC273FT TOSHIBA
