Bose ControlSpace ESP-00 II - Page 42

42
ELECTRICAL PART LIST
Transistors
Diodes
4x4 Series II PCB Assembly (optional on ESP-00 II)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
D500 1SS396 1SS396 TOSHIBA
D501 1SS396 1SS396 TOSHIBA
D502 1SS396 1SS396 TOSHIBA
D503 1SS396 1SS396 TOSHIBA
D504 1SS396 1SS396 TOSHIBA
D505 1SS396 1SS396 TOSHIBA
D506 1SS396 1SS396 TOSHIBA
D507 1SS396 1SS396 TOSHIBA
D600 DAN217 DAN217 RHOM
D601 DAN217 DAN217 RHOM
D602 DAN217 DAN217 RHOM
D603 DAN217 DAN217 RHOM
D604 DAN217 DAN217 RHOM
D605 DAN217 DAN217 RHOM
D606 DAN217 DAN217 RHOM
D607 DAN217 DAN217 RHOM
D608 OPEN NOT USED NOT USED
D700 1SR154-400 1SR154-400 RHOM
D701 1SR154-400 1SR154-400 RHOM
D702 OPEN NOT USED NOT USED
D703 OPEN NOT USED NOT USED
D704 OPEN NOT USED NOT USED
D705 OPEN NOT USED NOT USED
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
Q100 DTC114EKA DTC114EK
A
RHOM
Q101 DTC114EKA DTC114EK
A
RHOM
Q102 DTA114EKA DTA114EKA RHOM
Q103 DTA114EKA DTA114EKA RHOM
Q200 DTC114EKA DTC114EK
A
RHOM
Q201 DTC114EKA DTC114EKA RHOM
Q202 DTA114EKA DTA114EKA RHOM
Q203 DTA114EKA DTA114EKA RHOM
Q300 DTC114EKA DTC114EK
A
RHOM
Q301 DTA114EKA DTA114EKA RHOM
Q302 DTC114EKA DTC114EKA RHOM
Q303 2SC3326 2SC3326 TOSHIBA
Q304 2SC3326 2SC3326 TOSHIBA
Q305 2SC3326 2SC3326 TOSHIBA
Q306 2SC3326 2SC3326 TOSHIBA
Q307 DTC114EKA DTC114EK
A
RHOM
Q308 DTA114EKA DTA114EKA RHOM
Q309 DTC114EKA DTC114EKA RHOM
Q400 DTC114EKA DTC114EKA RHOM
Q401 DTA114EK
A
DTA114EKA RHOM
