Bose ControlSpace ESP-00 II - General Input;Output (GIO) PCB Assembly

55
ELECTRICAL PART LIST
General Input/Output (GIO) PCB Assembly
Resistors
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
R100 100 OHM, 0603, 1/10W, 1% Yageo RC0603F
R
-07100R
R101 100 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-07100R
R102 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R103 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R104 100 OHM, 0603, 1/10W, 1% Yageo RC0603F
R
-07100R
R105 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R106 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R107 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R108 5.1K, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-075K1
R109 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R110 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R111 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R112 5.1K, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-075K1
R113 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R114 5.1K, 0603, 1/10W, 1% Yageo RC0603FR-075K1
R115 5.1K, 0603, 1/10W, 1% Yageo RC0603F
R
-075K1
R116 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R117 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R118 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R119 10K, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-0710K
R120 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R121 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R122 10K, 0603, 1/10W, 1% Yageo RC0603F
R
-0710K
R123 10K, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-0710K
R125 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R126 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R129 0 OHM, 0603, 1/10W, 5% Yageo RC0603J
R
-07R00
R130 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R132 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R133 10K, 0603, 1/10W, 1% Yageo RC0603FR-0710K
R134 10K, 0603, 1/10W, 1% Yageo RC0603F
R
-0710K
R135 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R136 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R137 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R138 100 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-07100R
R139 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R140 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R141 100 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07100R
R142 100 OHM, 0603, 1/10W, 1% Ya
g
eo RC0603F
R
-07100R
R144 0 OHM, 0603, 1/10W, 5% Yageo RC0603JR-07R00
R145 330 OHM, 0603, 1/10W, 1% Yageo RC0603FR-07330R
R146 330 OHM, 0603, 1/10W, 1% Yageo RC0603F
R
-07330R
