ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Transistors
Integrated Circuits
Miscellaneous
Reference
Designator
Description
V
endor
V
endor Part Number Note
Q450 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q451 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q45
2
PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q453 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q454 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q455 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q456 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q457 PNP, 50V, 100Ma, SOT-23 KEC KRA102S
Q458 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Reference
Designator
Description
V
endor
V
endor Part Number Note
M100 SDRAM, TSOP-54 ELPIDA EDS1216AATA-75
M101 DSP, QFP-208 TI TMS320C6713BPYP
M200 PROG GATE ARRAY, QFP-208 XILINX XC2S150E6PQ208C
M201 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT
M202 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT
M300 MICROPROCESSOR, QFP-176 Renases HD6417706F133
M301 SDRAM, TSOP-54 ELPIDA EDS1216AATA-75
M302 FLASH MEMORY, TSOP-48 SPANSION S29GL064M90TAIR
M400 HEX INVERTER, TSSOP-14 ONSEMI MC74VHC04DT
M401 ETHER LAN CONT, TQFP-100 Cirrus CS8900A-CQ3
M450 TRANSCEIVER, SOIC-16 Harris/Intersil HIN202ECB
M452 OCTAL BUFFER DR, TSSOP20 ONSemi MC74VHC541DT
M453 VOLT DET, SOT-23-5 SEIKO S-80947CNMC-G9H-T2
M454 VOLT DET, TSOP-5 ONSEMI NCP303LSN11T1
M455 VOLT DET, SOT-23-5 SEIKO S-80917CNMC-G8M-T2
M456 VOLT DET, SOT-23-5 SEIKO S-80917CNMC-G8M-T2
M457 VOLT DET, Vd=3.0V SEIKO S-80930CNMC-G80-T2
M458 VOLT DET, SOT-23-5 SEIKO S-80940CNMC-G9A-T2
M460 REG, 3.3V, 1A, TO-252 NEC UPC2933T
M461 REG, SOT-223, TI NEC LM317DCY
M462 REG, SOT-223, TI NEC LM317DCY
M463 PWM SWITCHER TI TPS54312PWP
Reference
Designator
Description
V
endor
V
endor Part Number Note
CN452 CONN, SMT, 1.0MM, 100 PIN KEL 87BFN-100R
CN530 CONN, SMT, 100P Molex 52584-1079
X200 50.000MHz, 100
pp
m, 50
p
F KDS DSO531SVL 50MHz
X201 24.576MHz, 100ppm, 50pF KDS DSO531SVL
24.576MHz
