ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Inductors
Diodes
Reference
Designator
Description
V
endor
V
endor Part Number Note
C507 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C531 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C532 47
p
F, 0603, 50V, NPO, 55C, 5% Samsun
g
CL10C470JBNC
C533 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C534 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C535 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C536 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C537 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C538 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C539 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C540 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
Reference
Designator
Description
V
endor
V
endor Part Number Note
L100 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L300 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L301 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L302 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L400 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L401 XFMR, 10BASE-T, SOIC-16 E&E 821-M0542
L402 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L403 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L404 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L405 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L450 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L451 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L452 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L453 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L454 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L455 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC102R1H3D
L456 POWER IND, 5.2uH, 30% SUMIDA CDRH104R-5R2NC
L457 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
L458 EMI FILTER, 50V, 300mA, 20% Murata NFM21CC223R1H3D
Reference
Designator
Description
V
endor
V
endor Part Number Note
D450 SCHOTTKY, SC59 Toshiba 1SS 396
D451 SCHOTTKY, SC59 Toshiba 1SS 396
D453 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
D454 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
D455 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
D456 SCHOTTKY, SC59 Toshiba 1SS 396
D457 SCHOTTKY, SC59 Toshiba 1SS 396
D458 SCHOTTKY, SC59 Toshiba 1SS 396
D459 SCHOTTKY, SC59 Toshiba 1SS 396
D461 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
D462 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
D463 RECT, 400V, 1A, SOD-106 ROHM 1SR154-400
