52
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endor
V
endor Part Number Note
C456 0.047uF, 0603, X7R, 50V, 10% Samsung CL10B471KBNC
C457 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C458 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C459 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C460 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C461 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C462 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C463 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C464 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C465 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C466 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C467 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C468 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C469 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C470 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C471 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C472 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C473 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C474 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C478 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C479 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C480 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C481 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C482 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C483 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C484 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C485 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C486 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C487 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C488 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C489 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C490 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C492 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C493 100uF, ELEC, 16V, 40C, 20% NICHICON UWX1C101MCR1GB
C493 100uF, ELEC, 16V, 55C, 20% NICHICON UWT1C101MCR1GB
C494 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C495 0.047uF, 0603, X7R, 50V, 10% Samsung CL10B473KBNC
C496 0.047uF, 0603, X7R, 50V, 10% Samsun
g
CL10B102KBN
C
C497 470uF, TANT, 4V, 55C, 20% NICHICON F930G477MNC
C498 100uF, ELEC, 16V, 40C, 20% NICHICON UWX1C101MCR1GB
C498 100uF, ELEC, 16V, 55C, 20% NICHICON UWT1C101MCR1GB
C499 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C500 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C501 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C502 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C503 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C504 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C505 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C506 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
