Bose ControlSpace ESP-00 II - Page 49

49
ELECTRICAL PART LIST
Digital Signal Processor (DSP) PCB Assembly
Capacitors (continued)
Reference
Designator
Description
V
endor
V
endor Part Number Note
C139 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C140 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C141 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C142 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C143 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C144 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C145 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C146 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C147 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C148 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C149 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C150 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C151 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C152 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C153 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C154 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C155 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C156 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C157 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C158 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C159 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C160 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C161 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C162 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C163 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C164 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C165 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C166 0.1uF, 0603, Y5V, 50V, 20% Samsun
g
CL10F104ZBNC
C167 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C168 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C169 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C170 47pF, 0603, 50V, NPO, 55C, 5% Samsung CL10C470JBNC
C171 47
p
F, 0603, 50V, NPO, 55C, 5% Samsun
g
CL10C470JBNC
C172 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C173 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C174 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C175 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C176 47
p
F, 0603, 50V, NPO, 55C, 5% Samsun
g
CL10C470JBNC
C200 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C201 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C202 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C203 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C204 10uF, ELEC, 16V, 40C, 20% NICHICON UZT1C100MCR1GB
C205 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C206 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C207 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C208 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C209 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
C210 0.1uF, 0603, Y5V, 50V, 20% Samsung CL10F104ZBNC
