ELECTRICAL PART LIST
General Input/Output (GIO) PCB Assembly
Integrated Circuits
Miscellaneous
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
M100 VOLTAGE DETECTOR, TSOP-5 ONSEMI NCP303LSN30T1
M100 VOLTAGE DETECTOR, SOT-23-5 SEIKO S-80930CNMC-G80-
T2
M101 REGULATOR, 3.3V, 1
A
, TO-252 NEC UPC2933T
M102 FLASH, MCU, 32K, LQFP64 RENASES HD64F3664FP
M451 TRANSCEIVER, PDIP-8 TI SN75176BP
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
CN100 HEADER, RT ANG, 9 POS, P3.81 Dinkle ECH381
R
-09
P
CN101 HEADER, RT ANG, 9 POS, P3.81 Dinkle ECH381
R
-09
P
CN102 SHROUDED HEADER, TOP
ENTRY, 8 CKT, P=2.5
Neltron 2317SJ-08
CN400 JACK, MODULAR, TM5RJ2-88 HIROSE TM5RJ2-88
CN450 HEADER, RIGHT ANGLE,
P2.74MM, 9 PINS
Omron XM2C-0912-112
CN450 HEADER, RIGHT ANGLE,
P2.74MM, 9 PINS
WIESON 3170-09MANS4DW
CN451 HEADER, RIGHT ANGLE,
P5.08MM, 3 POLES, 2EHDRC-03P
DINKLE 2EHDRC-03P
XTAL300 32.768KHz, 20ppm, 12.5pF,
D3X8MM
Raltron R38-32.768-12.5
XTAL301 16.000MHz, 30ppm, 20pF, HC-
49/S
Raltron AS-16.000-20
XTAL400 20.000MHz, 30ppm, 20pF, HC-
49/S
Raltron AS-20.000-20
XTAL100 CRYSTAL, 10.000MHz, 30ppm,
20
p
F, HC-49/S
Raltron AS-10.000-20
BT450 COIN CELL, LITHIUM BATTERY
WITH SOLDERING TAB, BR2325
PANASONIC BR2325-1HCE 3
