ELECTRICAL PART LIST
General Input/Output (GIO) PCB Assembly
Inductors
Diodes
Transistors
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
L100 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L101 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L102 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L103 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L104 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L105 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L106 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L107 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L108 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L109 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L110 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L111 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L112 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L113 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L114 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L115 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L116 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L117 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
L118 EMI FILTER, SMD 300mA, 20% Murata NFM21CC223R1H3D
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
D108
R
ECTIFIER, 400V, 1
A
, SOD-106 ROHM 1SR154-400
D464 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW
D465 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW
D466 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW
D467 LED, RIGHT ANGLE, RED/GREEN KINGBRIGHT W42WUM/EGW
Reference
Designator
Description
V
endor
V
endor Part
Number
Note
Q100 NPN, 50V, 100mA, SOT-23 KEC KRC102
S
Q101 NPN, 50V, 100mA, SOT-23 KEC KRC102
S
Q102 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q103 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q104 NPN, 50V, 100mA, SOT-23 KEC KRC102
S
Q105 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q106 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q107 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q109 NPN, 50V, 100mA, SOT-23 KEC KRC102
S
Q110 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q111 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q112 NPN, 50V, 100mA, SOT-23 KEC KRC102S
Q113 NPN, 50V, 100mA, SOT-23 KEC KRC102
S
