ELECTRICAL PART LIST
Integrated Circuits
Miscellaneous
CC-16 Zone Controller
Reference
Designator
Description
V
endor Name
V
endor Part
Number
Note
U1 REG, 1.5A, TO-263 NS National Semi LM317S
U2 XCVR, SO-
8
, MAXIM Maxim Inte
g
rated MAX485ECSA
U3 EEPROM, 16Kx8, MSOP-8 Microchip Tech Inc 24LC128-I/MS
U4 MCU, SSOP28, 10MHz Microchip Tech Inc PIC16F873A-I/SS
Reference
Designator
Description
V
endor Name
V
endor Part
Number
Note
LCM LCD MODULE, BSE002
A
,
122X32 DOT
ShanTou Goworld
Co Ltd
SM4353
CN1 TERMINAL BLOCK, 6
P
,
ELK508A-06P, P=5.08MM
Dinkle Enterprise
Co Ltd
ELK508A-06P
CN2 HEADER, P2.54MM, DUAL,
20PIN, H7.5MM
Neltron Industrial
Co Ltd
2213S-20G
SW1 DIP SWITCH, 8 POLE, SPST,
ON/OFF, DS-08B
Diptronics
Manufacturing Inc.
DS-08B
X1 CRYSTAL, 9.8304MHz +/-
30ppm, 20pF, HC-49/S
Raltron Electronics AS-9.8304-20
