ELECTRICAL PART LIST
Resistors (continued)
4x4 Series II PCB Assembly (optional on ESP-00 II)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
R722 330 Ohm RK73H1JTD330RF KOA
R723 330 Ohm RK73H1JTD330RF KOA
R724 330 Ohm RK73H1JTD330RF KOA
R725 330 Ohm RK73H1JTD330RF KOA
R726 330 Ohm RK73H1JTD330RF KOA
R727 OPEN NOT USED NOT USED
R728 0 Ohm RK73Z1JTD 0RJ KOA
R729 OPEN NOT USED NOT USED
R730 10
k
RK73H1JTD10KF KOA
R731 10k RK73H1JTD10KF KOA
R732 10k RK73H1JTD10KF KOA
R733 10k RK73H1JTD10KF KOA
R734 10
k
RK73H1JTD10KF KOA
R735 OPEN NOT USED NOT USED
R736 33 Ohm RK73H1JTD33RF KOA
R737 33 Ohm RK73H1JTD33RF KOA
R738 OPEN NOT USED NOT USED
R739 OPEN NOT USED NOT USED
R740 0 Ohm RK73Z1JTD 0RJ KOA
R741 330 Ohm RK73H1JTD330RF KOA
R742 330 Ohm RK73H1JTD330RF KOA
R743 0 Ohm RK73Z1JTD 0RJ KOA
R744 OPEN NOT USED NOT USED
R745 OPEN NOT USED NOT USED
R746 4.7k RK73H1JTD4.7KF KOA
R747 33 Ohm RK73H1JTD33RF KOA
R748 33 Ohm RK73H1JTD33RF KOA
R749 OPEN NOT USED NOT USED
R750 OPEN NOT USED NOT USED
R751 0 Ohm RK73Z1JTD 0RJ KOA
RA703 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA
RA704 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA
RA705 RES ARRAY, 33 Ohm CN1J4KTD33RJ KOA
RA706 RES ARRAY, 10k MNR15E0RPJ103 RHOM
