40
ELECTRICAL PART LIST
Capacitors (continued)
4x4 Series II PCB Assembly (optional on ESP-00 II)
Reference
Designator
Description
V
endor Part Numbe
r
V
endor Name Note
C518 0.1uF GRM188F11E104ZA01D MURATA
C519 47uF, 16V MVK16VC47MF55 NICHIKEMI
C520 0.1uF GRM188F11E104ZA01D MURATA
C521 10uF, 16V MVK16VC10MD55 NICHIKEMI
C522 0.1uF GRM188F11E104ZA01D MURATA
C523 47uF, 16V MVK16VC47MF55 NICHIKEMI
C524 47pF GRM39CH470JZ01D MURATA
C525 47pF GRM39CH470JZ01D MURATA
C526 47
p
F GRM39CH470JZ01D MURATA
C527 0.1uF GRM188F11E104ZA01D MURATA
C528 0.1uF GRM188F11E104ZA01D MURATA
C550 10uF, 16V MVK16VC10MD55 NICHIKEMI
C551 0.1uF GRM188F11E104ZA01D MURATA
C552 47uF, 16V MVK16VC47MF55 NICHIKEMI
C553 0.1uF GRM188F11E104ZA01D MURATA
C554 10uF, 16V MVK16VC10MD55 NICHIKEMI
C555 0.1uF GRM188F11E104ZA01D MURATA
C556 10uF, 16V MVK16VC10MD55 NICHIKEMI
C557 0.1uF GRM188F11E104ZA01D MURATA
C558 0.1uF GRM188F11E104ZA01D MURATA
C559 10uF, 16V MVK16VC10MD55 NICHIKEMI
C560 0.1uF GRM188F11E104ZA01D MURATA
C561 10uF, 16V MVK16VC10MD55 NICHIKEMI
C562 0.1uF GRM188F11E104ZA01D MURATA
C563 47uF, 16V MVK16VC47MF55 NICHIKEMI
C564 0.1uF GRM188F11E104ZA01D MURATA
C565 10uF, 16V MVK16VC10MD55 NICHIKEMI
C566 47pF GRM39CH470JZ01D MURATA
C567 47pF GRM39CH470JZ01D MURATA
C568 47pF GRM39CH470JZ01D MURATA
C569 47pF GRM39CH470JZ01D MURATA
C570 0.1uF GRM188F11E104ZA01D MURATA
C571 0.1uF GRM188F11E104ZA01D MURATA
C572 47pF GRM39CH470JZ01D MURATA
C600 OPEN NOT USED NOT USED
C601 OPEN NOT USED NOT USED
C602 OPEN NOT USED NOT USED
C603 OPEN NOT USED NOT USED
C604 0.1uF GRM188F11E104ZA01D MURATA
C605 0.1uF GRM188F11E104ZA01D MURATA
C606 0.1uF GRM188F11E104ZA01D MURATA
C607 0.1uF GRM188F11E104ZA01D MURATA
C608 0.1uF GRM188F11E104ZA01D MURATA
C609 0.1uF GRM188F11E104ZA01D MURATA
C610 0.1uF GRM188F11E104ZA01D MURATA
C611 0.1uF GRM188F11E104ZA01D MURATA
