Bose PANARAY System

37
12.1 Bass Array Setup and Connections
Stereo Bank
802 Full Range
PANARAY D I
G
ITAL
S
Y
S
TEM
CO
NTR
O
LLE
R
PRESET
LIMIT
UTILITY
DELAY
Bose
®
Components:
1PANARAY
®
system digital controller
1 Bose 1800-VI power amplifier
2 2x broadside bass array brackets (top and bottom)
2 MB4 modular bass loudspeakers
Spacing:
In order to effectively create the MB4 2x endfire bass
array, each unit must be spaced 45" (114.3 cm) on
center from each other. This is shown in the illustra-
tion above. IF THE UNITS ARE NOT SPACED
PROPERLY THE BASS ARRAY WILL NOT WORK.
Note: All EQ and delay settings are already set in the
PANARAY system digital controller. In order for the
bass array to work, you must connect the MB4 units
to the appropriate outputs on the controller and apply
the proper spacing. The output assignments are list-
ed to the right.
MB4 2x Broadside Bass Array
Out 1
Out 2
MB4 1
MB4 2
0
90
180
270
Ho
r
i
z
.
Ve
r
t.
4
0H
z
0
90
180
270
Horiz.
Vert.
63Hz
0
90
180
270
Horiz.
Vert.
125Hz
MB4 2x Broadside Horizontal Octave-Band Polar Data
45"
(114.3 cm)
This array fires from the sides of both MB4
speakers to provide the dispersion shown above.
)zH081dnazH082(yarrassabedisdaorbx24BM
YARANAP

tuptuorellortnoclatigidmetsys
1HC)1(4BM
2HC)2(4BM
3HCdesutoN
4HCdesutoN
