Multi-DM™ User Manual Section 9 - DMShapes Software Overview
BMC Document Number: DOC-0009 Rev. 5.2 Page 41
9.2.9 To Save a Shape
1. On the Menu Bar click File, then click Save Shape As...
2. The Save Shapes As dialog will display.
3. Browse to the C:\Program Files\Boston Micromachines\Shapes folder.
4. In the File Name box enter a name for the shape file.
5. Click OK.
The current actuator values will be saved in a new Shape file.
Unless specified a .txt file name extension will be used.
Windows requires Administrator access to save to any subfolder of C:\Program Files.
The AOShapes dialog will display.
6. In the AOShapes dialog:
• To return to the DMShapes application click OK.
• To go to the directory where the shape was saved click Open.
9.2.10 To Find the Program Version
• On the Menu Bar click Help, then click About.
The DMShapes dialog will display with version information for the application
and the SDK. Please provide this information when contacting Boston Micromachines
for support.
9.2.11 To Close DMShapes
• On the Menu Bar click File, then click Quit.
The driver output for all actuators will be set to 0.
All actuators will return to their un-powered state.
The DMShapes application will close.
