Page 15 - Programming Manual 24805480/14-11-2012 319F92C ver. 1.2 -The data and information in this manual may be changed at any time with no obligation on BRAHMS’s part to notify anyone of this.
ENGLISH
AND/OR AREAS 001
INS. IF AREAS OR
And / or areas: (Default:
INS. IF AREAS OR
)
A
If you associate several areas to an input the input’s insertion status which is given
by the switched on/off status of the associated areas depends on this parameter:
INS. IF AREAS OR
Input inserted if at least one associated area is switched on.
Example: used when you wish to manage partialisations along with
the areas that share several inputs.
INS. IF AREAS AND
Input inserted if all of the associated areas are switched on.
Example: if there are two apartments that both share the same garage,
usually two areas are associated to the garage (one for each apartment)
and the AND function is enabled.
AREAS 001
#--
Associated areas:
(Default:
#--
)
F
S
A
The inputs can be freely associated to one or more areas. The behaviour of an input
which is associated to several areas depends on the value selected for the parameter
AND/OR AREAS
.
AND INPUT 001
NO
And input: (Default:
NO
)
A
An input, which is programmed in AND with another input, will alarm trigger only if
the second one is in alarm state. This parameter is normally used to have a double
consensus function to generate the alarm (via the x
+
–
Instantaneous you can set
this input).
Example: two sensors point to the same room and the user wants an alarm to be issued when both
sensors go into alarm mode.
INPUT 1 Type
INSTANTANEOUS
; And input
INPUT 2
.
INPUT 2 Type
INSTANTANEOUS
; And input
INPUT 1
.
AUTOEXCLUS. 001
[0..10 0=NO] 03
Auto exclude input: (Default:
03
)
S
A
It defines the number of times that the input can switch to alarm, beyond which said
input is automatically excluded. The alarm counter resets and the input re-includes
itself if at least one of the associated areas switches off.
Example: A traditional example are outside detectors.
BUZZ.OUPUT 001
NO
Buzzer output: (Default:
NO
)
S
A
For choosing whether the input will activate the “buzzer output” or not, or the
keypads activated to sound along with the buzzer output. Always active independent
from the statuses of the associated areas.
Example door open bell: a typical use of this function is to make the key pad sound after a shop
door is opened.
Area 1: indoors.
Area 2: perimetral.
Keypad 1: positioned loose to sound; Associated areas
##--
.
Front door entrance: Buzzer output:
YES
;Associated areas
-#--
.
Keypad buzzer output:
#---
.
Perimetral area buzzer time
3
seconds.
OUTPUT ASSOC 001
NO
Associating output: (Default:
NO
)
S
A
Assign the output to activate if the input is unbalanced. If the commanded output
is stable, when the input unbalances the output activates, if it balances the output
deactivates. If the output is impulsive, it activates and starts the timer when the input
unbalances.
Depending on the
OUTPUT COMM.
parameter, managing the output may be linked
to the input’s inserted status.
