No. Name Article No.
②
Instrument Adapter Array (Size M)
Instrument Adapter Array (Size ML)
Instrument Adapter Array (Size L)
Instrument Adapter Array (Size XL)
41798
41799
41801
41802
③
Tool for Instrument Adapter 41796-27
NOTE: Any instrument adapter clamp can be attached to any array. If you exchange the array for
one of a different size during the procedure, recalibrate and verify the instrument before
continuing.
Proper Handling of Instrument Adapters
Warning
Ensure the adapter array is large enough for the instrument. The larger the instrument, the
larger the adapter array you should use. An adapter array that is too small can result in
imprecise calibration or navigation.
Warning
Ensure that you use the correct size Instrument Adapter Clamp according to the diameter
of the instrument.
Warning
Do not use on conical instruments.
Warning
Only use on metal surfaces.
Warning
Only use on non-motorized instruments.
Arrays and Clamps
