SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
9 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
Item
No
Description
Indicator Cover Screws
Lockwasher
Position Indicator Cover
O-Ring
Cover Fastening Screw
Cover
O-Ring
Position Indicator
Cam Assembly
 Switch Plate Mounting Screw
 Switch Plate
 Limit Switch Screw
 Limit Switch Bracket
 Main OpenClosed Limit Switches
 Limit Switch Insulator
 Heater Bracket Screw
 Heater Mounting Bracket
 Heater
 Override Switch Trigger Pin
 Override Switch
 Override Switch Insulator
 Override Switch Screw
 Switch Plate Ball Bearing
 Retaining Ring
 Coupler
 Worm Wheel
 O-Ring
 Terminal Strip
 Capacitor
 Spring Pin
 O-Ring
 Nylon Flat Washer
 Travel Stop Nut
 Travel Stop Spacer
 Travel Stop Bolt
 Worm Shaft
 Override Drive Pin
 Spring Pin
 Manual Override Shaft Hub
Item
No
Description
 Spring Plunger
 Manual Override Shaft Stub
 Manual Override Sleeve
 O-Ring
 O-Ring
 Retaining Ring
 Handwheel
 Spring Pin
 Manual Override Bushing
 Thrust Washer
 Thrust Roller Bearing
 Thrust Washer
 Disc Spring
 Disc Spring
 Worm
 Spring Pin
 Retaining Ring
 Thrust Washer
 Base
 Conduit Plug
 Name Tag
 Bushing
 Gear Spacer
 Drive Gear
 Spring Pin
 Retaining Ring
 Gearmotor
 Lock Washer
 Motor Cap Screw
 Dowel Pin
 Wire Entry Guard
 Terminal Strip Marker
 Terminal Strip
 Terminal Block Screw
 Ground Terminal Washer
 Ground Terminal Screw
 Torque Switch Cover
 Aux OpenClosed Limit Switches
 Series  – Size E E E – Parts
