only once. It can also represent a legally valid IPv4 address. For example,
::192.1.2.34. The field may be left blank if IPv6 operation on the interface
is not desired.
IPv6 Mask: The IPv6 network mask, in number of bits (prefix length).
Valid values are between 1 and 128 bits for an IPv6 address. The field
may be left blank if IPv6 operation on the interface is not desired.
IP Routes: This section is use to configured the routing options for the IP
interfaces configured. The configurable fields for this section are:
Delete: Select this option to delete an existing IP route
Network: The destination IP network or host address of this route. Valid
format is dotted decimal notation or a valid IPv6 notation. A default route
for IPv4 is configured using 0.0.0.0 . A default route for IPv6 is configured
using “::” notation.
Mask Length: The destination IP network or host mask, in number of bits
(prefix length). It defines how much of a network address that must
match, in order to qualify for this route. Valid values are between 0 and
32 bits respectively 128 for IPv6 routes. Only a default route will have a
mask length of 0 (as it will match anything).
Gateway: The IP address of the IP gateway. Valid format is dotted
decimal notation or a valid IPv6 notation. Gateway and Network must be
of the same type.
Next Hop VLAN(Only for IPv6): The VLAN ID (VID) of the specific IPv6
interface associated with the gateway. The given VID ranges from 1 to
4094 and will be effective only when the corresponding IPv6 interface is
valid. If the IPv6 gateway address is link-local, it must specify the next
hop VLAN for the gateway. If the IPv6 gateway address is not link-local,
system ignores the next hop VLAN for the gateway.
Radios Default IP configuration
The unit will configured with the following default settings:
Low Band Unit: Mode: Host
IP address: 10.100.7.247
Mask Length: 24
IP Route: None
High Band Unit: Mode: Host
IP address: 10.100.7.248
