2-2
OPERATIONAL LOCKOUTS
Indicator lights illuminate to show “Opera-
tion Lockout” conditions that need to be
corrected before unit will function. Unless
noted otherwise, all control functions shut
down.
15. Product Door Indicator Light: Illumi-
nates when the Product Door is open.
Note: All control functions are active
except “Start” or “Stop” functions.
16. Access Door Indicator Light: Illumi-
nates when the Access Door is open.
17. Element Up Indicator Light: Illumi-
nates when the heating element is in
the raised position.
18. Air Flow Indicator Light: Illuminates
when the flow of air through the Air Fil-
ter area falls below acceptable level.
Replace Air Filter every 3
months.
19. Air Filter Indicator Light: Illuminates
when the air filter is not installed in the
unit.
20. Grease Filter Indicator Light: Illumi-
nates when the grease filter is not
properly installed in the unit (magnet to
the right).
21. Hi-Limit Control Indicator Light:
Prevents oil temperature from exceed-
ing 475° F. If power to control turns off
due to Hi-Limit Control, this indicator
light will illuminate, press the OFF but-
ton and DO NOT attempt to operate
until it has been serviced by an autho-
rized Broaster Company representa-
tive.
22. Fire System Light: Illuminates when
6 months have passed to indicate
semi-annual maintenance is due on
fire suppression system. See Section 7
“Fire Suppression System” in Installa-
tion & Operation Manual for proper
procedure by certified service person-
nel.
All Control functions
remain active if this light
comes on. To reset light for 6 more
months, press & hold “STOP” & “#6” but-
tons for 10 seconds.
CONTROLLER BASIC
PROGRAMMING
NORMAL OPERATING MODE
Check oil level before
pressing the ‘ON’ button.
Action: Press ‘ON’ button.
Response: Green “Power On” light
illuminates and Temp Display alter-
nates between number values for cook
temperature, and LO (idle mode). LO
will disappear when oil temperature
has reached cook temperature value.
Time Display will show the set time in
minutes and seconds.
Set Temperature:
Action: Press Cook Temperature But-
ton twice within 5 seconds.
Response: Programming mode has
been entered. Flashing Temp Display
reads “###F.” (### = temperature value
ie: 360F)
Action: If desired, press keypad num-
bers to change displayed value then
press Cook Temperature Button once
to enter new value into memory.
broaster.com Manual #16501 8/06 Rev 10/20
