Broaster VF-2 - Electrical Components; Access for Service; Motor Replacement

5 - ELECTRICAL COMPONENTS
5-1
ACCESS FOR SERVICE
1. Disconnect main power supply.
2. Remove Access Panel Retaining
Screw (1). Raise the Access Panel (2)
and pull outward.
1
2
MOTOR REPLACEMENT
1. See Access For Service.
2. Open Access Door (3) by lifting Access
Door Latch (4) and turning CCW.
3
4
broaster.com Manual #16501 7/06 rev 2/15
