Brocade FastIron, FCX, ICX, and TurboIron Diagnostic Reference 47
53-1002965-01
Link aggregation debug commands
3
debug packet-capture filter show
Syntax: debug packet-capture filter show [ all | decimal ] none
This command displays the filter information for the particular filter index. The decimal variable
refers to the number of the packet captured for filter.
Execute the following command to display the complete filter information.
Brocade# debug packet-capture filter show all
Filter 1:
Match STP
Filter 2:
Match 802.1W
Execute the following command to display filter information for a particular filter number.
Brocade# debug packet-capture filter show 2
Filter 2:
Match 802.1W
Execute the following command to remove all the filters that are configured.
Brocade# debug packet-capture filter none
Link aggregation debug commands
The trunk group feature allows you to manually configure multiple high-speed load-sharing links
between two Brocade Layer 2 switches or Layer 3 switches or between a Brocade Layer 2 switch
and Layer 3 switch and a server.
In addition to enabling load sharing of traffic, trunk groups provide redundant, alternate paths for
traffic if any of the segments fail. Trunk groups are manually configured aggregate links containing
multiple ports. The 802.3ad link aggregation protocol dynamically creates and manages trunk
groups.
The terms "trunk group" and "link aggregation group" are used interchangeably in this document.
The following commands are used for troubleshooting trunk groups:
• debug pp-trunk-hash
• debug pp-bum-trunk-hash
