Introduction 8200 Compressor
Installation, Operation and Servicing InstructionsInstallation, Operation, and Service In-
8040353 Brooks Automation
1-6 Revision AA
Interface Cold head power receptacle: Mates with plug on cold
head power cable.
On-Board power receptacle: Mates with plug on cold-
head power cable.
Compressor input-power terminal block enclosure: Mates
with input power cable, fabricated by customer or avail-
able from BROOKS-Cryogenics.
Gas-supply connector: 1/2-inch self-sealing coupling
Gas-return connector: 1/2-inch self-sealing coupling
Adsorber service
schedule
Replace every 12 months.
Cooling water require-
ments (water cooled
only)
100°F (38°C) maximum discharge temperature
Refer to Table 1-1 on page 1-5, Figure 1-1 on page 1-3, and
Figure 1-2 on page 1-4, for parameters.
Table 1-2: General Specifications (Continued)
Specification Description
