Brooks 8200 - Cooling Water: Heat Load and Temperature Rise

8200 Compressor Installation
Installation, Operation, and Service Instructions Preparing the Compressor Input-Power
Brooks Automation 8040353
Revision AA
4-7
Figure 4-3: 8200 Compressor Cooling Water Flow and Pressure Requirements
Figure 4-4: 8200 Compressor Water Cooling Requirements
Cooling Water: Heat Load and Temperature Rise
Heat load to facility water is approximately 5000
Btu/hr, or 1500 Watts. With a 1.0
GPM water flow this translates to an approximate water temperature rise of 10ºF
(5.6ºC)
0.25 0.50 0.75
1.00
1.50
1.75
2.00
0
10
20
30
40
50
60
Minimum Required water Pressure (PSIG)
Water Flowrate (GPM)
Allowable
Operating
Ra n g e
at min. water flowrate
40
45
50
55
60
65
70
75
80
85
90
0.25 0.50 0.75 1.00 1.50
1.75
2.00
Water Supply Temperature (ºF)
Water Flowrate (GPM)
Allowa b le
Operating
Ra n g e
