Brooks 8200 - Power Requirements (Steady-State Conditions); General Specifications

8200 Compressor Introduction
Installation, Operation, and Service InstructionsInstallation, Operation and Servicing In-
Brooks Automation 8040353
Revision AA
1-5
Table 1-1: Power Requirements (Steady-State Conditions)
Part Number Cooling Phase Hz
Operating
Voltage
Range
Nominal
Operating
Current
Rated Full
Load / Locked
Current
8032549G001
Air
Air
3
3
50
60
180-220
198-250
10A
10A
12/30A
8032549G002
Air
Air
1
1
50
60
180-220
198-250
10A
10A
12/30A
8032550G001
Water
Water
3
3
50
60
180-220
198-250
8.5A
8.5A
12/30A
8032550G002
Water
Water
1
1
50
60
180-220
198-250
8.5A
8.5A
12/30A
*See the nameplate on the back of the compressor for more details.
Table 1-2: General Specifications
Specification Description
Weight 150 lbs (68 kg) max.
Weight
(shipping)
155 lbs (70 kg) max.
Power
consumption
2.0 kw, nominal operating(water), 2.1 kw nominal operat-
ing (air)
Compressor input-
power cable
(customer-supplied)
Recommended type SO-4 conductor, 600V, neoprene
jacket and 14-gauge wire.
Install per Appendix C: Electrical Schematics for 8200
Compressor on page 6-8, Electrical Schematic diagram,
ensuring compliance with all national, state and local
standards.
Helium pressure Static: 245-255 psig (1688-1757 kPa) at 70 to 80°F (21 to
27°C)
Supply: nominal operation: 270-290 psig (1860-2000 kPa)
at operating temperature.
Ambient operating
temperature range
50 to 100°F (10 to 38°C)
