Safety 8200 Compressor
Safety Shape Descriptions Installation, Operation, and Service Instructions
8040353 Brooks Automation
2-4 Revision AA
Safety Shape Descriptions
All cautions and warnings contain safety shapes, which have specific safety mean-
ings. The following table shows some of the safety shapes used in this document and
their meanings.
References
For more information about safety standards, see the following documents:
• ISO 7010: 2003(E), Graphic symbols - Safety colours and safety signs - Safety
signs used in workplaces and public areas
• ISO 3864-1: 2002(E), Graphic symbols - Safety colours and safety signs - Part 1:
Design principles for safety signs in workplaces and public areas
Table 2-2: Safety Shapes
Example Term Shape Definition
General Warning
Indicates a general hazard. Details
about this hazard appear in the safety
notice explanation.
High Voltage Indicates a high voltage hazard.
Hot Surface
Indicates a surface is hot enough to
cause discomfort or a burn.
