Brooks 8200 - Page 41

8200 Compressor
Installation, Operation, and Service Instructions
Brooks Automation 8040353
Revision AA
6-1
6 Appendices
Overview
The following appendices are included to provide the user with a single location for
specific information related to the Brooks Automation Product.
Contents
Appendix A: Customer Brooks Automation Technical Support Information . . .6-3
Appendix B: Troubleshooting Procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-4
Appendix C: Electrical Schematics for 8200 Compressor . . . . . . . . . . . . . . . . . . . .6-8
Appendix D: Components in the Electrical Control Module of the 8200 Compressor
6-11
Appendix E: Flow Diagrams for 8200 Air-Cooled and Water-Cooled Compressors6-
13
Appendix F: Additional Cooling Water Quality Parameters . . . . . . . . . . . . . . . . .6-16
