Brother DCP-B7500D Service Manual

2-22
Confidential
Error
Codes
Description
Refer
to:
Error
Codes
Description
Refer
to:
8A01
The registration rear sensor detected
that the paper fed was smaller or larger
than the specified size in duplex
printing mode.
2-61
9203 ---
8A02 --- 9204 ---
8B01 --- 9205 ---
8C00
There is no paper set in the manual feed
slot on the manual feed slot printing.
2-61 9206 ---
8D01 --- 9301
When paper was fed from the MP tray,
the MP paper empty sensor detected
that no paper was in the MP tray.
2-63
8D02 --- 9302
When paper was fed from the paper
tray, the T1 paper empty sensor or T1
paper feed sensor detected that no
paper was in the paper tray.
2-63
8E01
Paper size is not set as A4/Letter/
Legal/Folio when receiving fax or
printing a list/report.
2-62 9303 ---
8E02
Detected that the size of paper set in the
paper tray was over 10 mm shorter than
paper size set in the machine during
faxing or printing a list or report.
2-62 9304 ---
8F01 --- 9305 ---
8F02 --- 9306 ---
8F03 --- 9309
Detected that there was no paper set
in all trays when TrayAuto was
selected for printing.
2-64
9001
The size of paper loaded in the MP
tray and the one specified from the
driver are not same when paper is fed
from the MP tray.
2-62 930A
Paper ran out during Fax / List
continuous printing.
9002
The size of paper loaded in the paper
tray and the one specified from the
driver are not same when paper is fed
from the paper tray.
2-62
9501 ---
9003 --- 9502 ---
9004 --- 9503 ---
9005 --- 9504 ---
9006 --- 9505 ---
9102 --- 9601 ---
9103 --- 9608 ---
9104 --- 9701
For 2-sided printing, paper size setting of
the printer driver that was not supported
by 2-sided printing was selected.
2-64
9105 --- 9702
For printing by feeding paper from the
paper tray, the size of paper specified
from the driver set the size which was
not supported by the paper tray.
2-64
9200 --- 9703 ---
9201
When printing from the MP tray, paper
type setting in the machine does not
match the setting in the driver.
2-62 9704 ---
9202
When printing from the paper tray,
paper type setting in the machine does
not match the setting in the driver.
2-62 9705 ---

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
