Brother DCP-B7500D Service Manual

2-27
Confidential
Journal Full -
The number of the registered
communication management
reports reached 200.
--- 4.14.5
Machine Error -
Detected that the modem PCB
is not connected.
D200 2-70
Machine Error
F9
-
The spec code was not entered
correctly.
F900 2-72
Manual Feed Load Paper.
There is no paper set in the
manual feed slot on the manual
feed slot printing.
8C00 2-61
Media
Mismatch
Reload correct
paper in MP Tray,
then press Go.
When printing from the MP tray,
paper type setting in the
machine does not match the
setting in the driver.
9201 2-62
Reload correct
paper in Tray 1, then
press Go.
When printing from the paper
tray, paper type setting in the
machine does not match the
setting in the driver.
9202 2-62
No Cartridge Put the Toner
Cartridge back in.
Toner cartridge could not
communicate with the cartridge
sensor.
2500 2-51
No Drum Unit Open the Front
Cover, then install
the Drum Unit.
Detected that the drum unit was
not set by detecting the
electrodes current.
6200 2-55
No Paper Reload paper in
Tray.
Detected that there was no
paper set in all trays when
TrayAuto was selected for
printing.
9309 2-64
Detected that there was no
paper set in all trays when
TrayAuto was selected for
printing.
(At Fax / List printing)
--- 4.2.1
No Paper MP Reload paper in MP
Tray.
When paper was fed from the
MP tray, the MP paper empty
sensor detected that no paper
was in the MP tray.
9301 2-63
When paper was fed from the
MP tray, the MP paper empty
sensor detected that no paper
was in the MP tray.
(At Fax / List printing)
--- 4.2.2
Error message
Description
Error
codes
Refer
to:
Initial display Scroll

Brother DCP-B7500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	34 ppm
Printing colors	Black
Duplex functions	Print
Maximum duty cycle	15000 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Duplex copying	-
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
Scan to	E-mail, File, Image
Input color depth	30 bit
Output color depth	24 bit
Input grayscale depth	10 bit
Output grayscale depth	8 bit
Optical scanning resolution	1200 x 1200 DPI
Faxing	No
Total input capacity	250 sheets
Total output capacity	120 sheets
Paper tray media types	Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 230 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Maximum ISO A-series paper size	A4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Product color	Gray
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 10.2 Jaguar, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur
Windows operating systems supported	Windows 10, Windows 7, Windows 8, Windows 8.1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.03 W
Power consumption (ready)	42 W
Power consumption (sleep)	6.2 W
Power consumption (printing)	485 W

Weight and Dimensions

Depth	398.5 mm
Width	410 mm
Height	272 mm
