Brother DreamWeaver„ VQ3000 User Manual

ENTERING STITCH DATA
MY CUSTOM STITCH
Sewing S-105
S
4
■ Key Functions
a This area displays the stitch being created.
b Displays the number of the present set point over the total number of points in the stitch.
c Displays the y-coordinate of over the x-coordinate of .
ENTERING STITCH DATA
No. Display Key Name Explanation Page
d Single/triple stitching
key
Press this key to select whether one or three stitches will be sewn
between two points.
S-106
e Point delete key Press this key to delete a selected point. S-107
f Return key Press this key to exit the entering stitch data screen. —
g Test key Press this key to sew a test of the stitch. S-107,
S-110
h “MY CUSTOM STITCH”
memory key
Press this key to store the stitch being created. S-110
i Block move key Press this key to group points together and move them together. S-108
j Insert key Press this key to insert new points on the stitch design. S-109
k Set key Press this key to set a point on the stitch design. S-106 to
S-108
l
Arrow keys
Use these keys to move over the display area.
S-106 to
S-109
m
Point-to-point key
Use these keys to move from point to point on the stitch, or to
the first or last point entered on the stitch.
S-107 to
S-109
n Image key Press this key to view an image of the stitch. S-107
o Grid direction key Press this key to change the direction of the grid sheet. S-106
p Enlarger key Press this key to see an enlarged version of the stitch being created. S-106
a
m
i
h
g
b
d
f
c
e
l
k
j
p
n
o
