3-17
Confidential
9 Scanner unit
Harness colors are subject to change for some reason.
First side CIS flat cable
FB harness
unit (WH)
Flat coreFlat core
Panel FG harness (GN)
Panel harness (WH)
Panel harness (WH)
<For models with touch panel> <For models without touch panel>
First side CIS flat cable
FB harness
unit (WH)
