Brother HL-L2300d Series Service Manual

5-19
Confidential
1.3.11 Display LAN connection status (function code: 33)
<Function>
This function is used to check the connection status of the wired LAN.
<Operating Procedure>
LCD LAN connection status
Active 100B-FD 100B-FD
Active 100B-HD 100B-HD
Active 10B-FD 10B-FD
Active 10B-HD 10B-HD
Inactive Not connected
For models without keypad
(1) Press the [▲] or [▼] key in the initial
state of maintenance mode to display
"MAINTENANCE 33" on the LCD, and
press the [OK] key. One of the following
items is displayed on the LCD
depending on the wired LAN connection
of the machine.
(2) When the [Stop] key is pressed, the
machine returns to the initial state of
maintenance mode.
For models with keypad
(1) Press the [3] key twice in the initial state
of maintenance mode. One of the
following items is displayed on the LCD
depending on the wired LAN connection
of the machine.
(2) When the [X] or [Stop] key is pressed,
the machine returns to the initial state of
maintenance mode.

Brother HL-L2300d Series Specifications

General

Functions	Print
Standard Paper Capacity (sheets)	250
Standard Interface(s)	USB 2.0
Print Resolution (maximum dpi)	2400 x 600 dpi
Recommended Monthly Print Volume	250 - 2, 000 pages
Operating System Compatibility	Windows, Mac, Linux
