Brother HL-L2300d Series Service Manual

1-2
Confidential
Model DCP-7080
DCP-7080D
DCP-L2500D
DCP-L2520D
DCP-L2520DW
DCP-L2540DN
DCP-7180DN
DCP-L2540DW
DCP-L2541DW
DCP-L2560DW
HL-L2380DW
Warm-up
time
From Sleep
mode
Less than 9 seconds at 73.4F (23°C)
Less than 10
seconds at
73.4F (23°C)
(except for
Oceania)
Less than 9
seconds at
73.4F (23°C)
(for Oceania)
From Power
OFF
 ON
Less than 28 seconds at 73.4F (23°C)
First print
time
From Ready
mode
Less than 8.5 seconds at 73.4F (23°C)
From Sleep
mode
Less than 17.5 seconds at 73.4F (23°C)
CPU
ARM9 266 MHz
Backup Clock N/A
Dimensions
(W x D x H)
Carton size 567 x 517 x 414 mm
(22.3 x 20.4 x 16.3 inch)
567 x 517 x 435 mm
(22.3 x 20.4 x 17.1 inch)
567 x 517 x
414 mm
(22.3 x 20.4
x 16.3 inch)
Machine size
409 x 398.5 x 267 mm
(16.1 x 15.7 x 10.5 inch)
409 x 398.5 x 316.5 mm
(16.1 x 15.7 x 12.5 inch)
409 x 398.5
x 267 mm
(16.1 x 15.7
x 10.5 inch)
Specifications are subject to change without notice.

Brother HL-L2300d Series Specifications

General

Functions	Print
Standard Paper Capacity (sheets)	250
Standard Interface(s)	USB 2.0
Print Resolution (maximum dpi)	2400 x 600 dpi
Recommended Monthly Print Volume	250 - 2, 000 pages
Operating System Compatibility	Windows, Mac, Linux
