Brother MFC-7380

To Next Page

To Previous Page

2-4

Confidential

2. OVERVIEW

2.1 Cross-section Drawing

2.1.1 Printer part

Fig. 2-2

Eject roller 2 Exposure drum Laser unit Registration rear actuator

Registration front actuator

Manual feed slot

Paper dust

cleaning roller

Paper feed

actuator

Separation pad

Separation rollerPick-up rollerPlateDuplex paper feed rollerPressure rollerDuplex tray

Heat roller

Eject actuator

Eject roller 1

Back cover

Registration roller
