Troubleshooting and routine maintenance
11 - 9
11
4
Pull the tab toward you to open the rear
chute cover.
5
Pull the jammed paper out of the fuser
unit. If the jammed paper cannot be
pulled out easily, push down the blue tab
with one hand as you gently pull out the
paper with the other hand.
6
Close the back cover.
7
Put the drum unit and toner cartridge
assembly back into the machine.
8
Close the front cover.
