General information
9
1
9 Wireless Status
A four-level indicator on the Ready mode
screen shows the current wireless signal
strength if you are using a wireless connection.
If you see at the top on the screen, you
can easily configure the wireless settings by
pressing it. For more information, see Quick
Setup Guide.
10 Faxes in memory
Shows how many received faxes are in the
memory.
The warning icon appears when there is
an error or maintenance message. For
information about error messages, see Error
and Maintenance messages on page 83.
When the Distinctive Ring feature is
turned on, the Touchscreen shows D/R.
For more information, see Distinctive Ring
on page 47.
Basic Operations 1
To operate the Touchscreen LCD, press your
finger on the Touchscreen to operate it. To
display and access all the settings and
features tables and the available options,
press s or t on the Touchpanel to scroll
through them.
DO NOT press the Touchscreen with a
sharp object, such as a pen or stylus. It
may damage the machine.
The following steps show how to change a
setting in the machine. In this example the
Receive Mode setting is changed from
Fax Only to Fax/Tel.
a Press (Settings).
b Press s or t on the Touchpanel to
display Initial Setup.
c Press Initial Setup.
d Press s or t to display
Receive Mode.
e Press Receive Mode.
f Press s or t to display Fax/Tel.
